VVDI XSADJ1GL For Audi 754J Smart key with adjustable frequency 315mhz/433mhz/868mhz
or Whatsapp: +86-15889291896 or
Email: info@onlyda.com
-
- Product Name: VVDI XSADJ1GL For Audi 754J Smart key with adjustable frequency 315mhz/433mhz/868mhz
- Item NO.: VVDI-XS02
- Weight: 0.04 kg = 0.0882 lb = 1.4110 oz
- Volume: 131 CBM
- Category: Xhorse VVDI Brand
- Tag: XSADJ1EN , xhorse1 , N2085
- Brand: Xhorse
- Creation Time: 2022-06-24
- VVDIXSADJ1GL For Audi 754J Smart key with adjustable frequency 315mhz/433mhz/868mhz
global version
VVDI XM38 754J Smart Key Generation Issue ：
Problem Description：
Some customers have reported failed generation of VVDI XM38 754J smart keys : after generation is completed, the key board has no frequency output and the indicator light does not illuminate.
This issue is caused by incompatibility between the key board chip version and the generation program:
The 754J key board is available with different chip versions.
When generation program only supports the XM4632 chip version (as shown in the attached image).
If the key board uses a different chip version, or if an incorrect generation program is selected, the key will fail to activate its RF function after programming.
Solution Steps ：
1. Verify the Chip Model
Open the key board and check the main chip marking. Confirm it is XM4632 (as indicated in the reference image on Onlyda website). If the chip marking is different, a compatible generation program or key board must be used.
2. Select the Correct Generation Program
In the VVDI device, choose the program labeled "754C/G/J/D Smart 315/433/868 (XM4632)", which specifies "Only supports XM4632 version". Follow the program's instructions strictly to complete the generation process; do not use other versions of the generation program.
3 .Post-Generation Verification
After generation, test if the indicator light illuminates when pressing the key buttons, and confirm the device detects a 315mhz /433mhz frequency output. Please note 868 mhz will not detected by VVDI device ，but it can work normally .
If no frequency is detected, check for proper chip soldering, ensure the battery is functional, or try another key board with an XM4632 chip.
